Panel Gate Round
Universal for 2D and 3D panel
Easy and fast installation
Universal opening
Rigidity
product description
DESCRIPTION
Panel Gate Round is universal for both 2D and 3D panel using round posts. Available in single and double version. Mesh opening match most panel fences.
FINISH:
Galvanized and polyester coated | |
  |  |
| Nominal width mm | Nominal height mm | Gate post mm | Gate post length mm | Frame profile mm | Infill mm | |
| 1000 | 1000 | Φ60x2.0 | 1500 | Φ40 | 200x55x5.0 |  |
| 1000 | 1200 | Φ60x2.0 | 1700 | Φ40 | 200x55x5.0 | |
| 1000 | 1500 | Φ60x2.0 | 2000 | Φ40 | 200x55x5.0 | |
| 1000 | 1800 | Φ60x2.0 | 2300 | Φ40 | 200x55x5.0 | |
| 1000 | 2000 | Φ60x2.0 | 2500 | Φ40 | 200x55x5.0 | |
| 1200 | 1000 | Φ60x2.0 | 1500 | Φ40 | 200x55x5.0 |  |
| 1200 | 1200 | Φ60x2.0 | 1700 | Φ40 | 200x55x5.0 | |
| 1200 | 1500 | Φ60x2.0 | 2000 | Φ40 | 200x55x5.0 | |
| 1200 | 1800 | Φ60x2.0 | 2300 | Φ40 | 200x55x5.0 | |
| 1200 | 2000 | Φ60x2.0 | 2500 | Φ40 | 200x55x5.0 | |
| 3000 | 1000 | Φ76x2.0 | 1500 | Φ40 | 200x55x5.0 |  |
| 3000 | 1200 | Φ76x2.0 | 1700 | Φ40 | 200x55x5.0 | |
| 3000 | 1500 | Φ76x2.0 | 2000 | Φ40 | 200x55x5.0 | |
| 3000 | 1800 | Φ76x2.0 | 2300 | Φ40 | 200x55x5.0 | |
| 3000 | 2000 | Φ76x2.0 | 2500 | Φ40 | 200x55x5.0 | |
| 4000 | 1000 | Φ76x2.0 | 1500 | Φ40 | 200x55x5.0 |  |
| 4000 | 1200 | Φ76x2.0 | 1700 | Φ40 | 200x55x5.0 | |
| 4000 | 1500 | Φ76x2.0 | 2000 | Φ40 | 200x55x5.0 | |
| 4000 | 1800 | Φ76x2.0 | 2300 | Φ40 | 200x55x5.0 | |
| 4000 | 2000 | Φ76x2.0 | 2500 | Φ40 | 200x55x5.0 |
